Description
- Maximum length of cut 3200 mm,
- Maximum pusher stroke 3200 mm,
- Maximum saw blade projection 75 mm,
- Maximum gripper opening 65 mm,
- Height of work table 985 mm,
- Main saw motor power 7.5 kW (10 HP),
- Scoring saw motor power 2.2 kW (3 HP),
- N. 1 Rounded air table 2050 x 620 mm with square support – left hand side,
- N. 6 Pneumatic grippers (at 50 – 150 – 360 – 1530 – 2280 – 3030 mm),
- Additional pneumatic gripper in position 570 mm,
- Air conditioning device for the electrical cabinet,
- N. 2 Rounded air cushion unloading table, size 2050 x 620 mm.
