Description
- Max cutting thickness: 80mm (for blade diameter 350mm)
- Max cutting width: 320 mm
- Min distance between movable and stationary saw blades: 30 mm
- Max width of board passage: 650 mm
- Min length of workpieces: 400 mm, optional short pieces device included
- Diameter of movable saw blades: min/max 300/350 mm, hole diameter 75, 2 pcs. Keyway 24 x 6
- Diameter of fixed saw blades: min/max 300/350 mm, hole diameter 70, 2 pcs. Keyway 20 x 6
- 4 independent pressure rollers
- Anti kickback device
- Main motor versions: 22 kW
- Feed speed adjustable by inverter: 0-36 m/min
- Feed belt motor: 1.5 kW
- Feed belt width: 350 mm
- Upper dust extraction port: Ø 250 mm, 30 m/s, 5300 m³/h
- Lasers set indicating the position of the saws
- Reinforced feed belt
- Automatic oil pump
- Front remote control board
- Weight: 2100 kg
Machine dimensions:
- Length: 191 cm
- Width: 190 cm
- Height: 170 cm
