Description
- Working width 630 mm
- Minimum / maximum working height 3 / 310 mm
- Maximum material removal 8 mm
- Spiral spindle diameter 120 mm
- Number of knives 3
- Cutter rotation speed 4800 rpm
- Feed speed with inverter 6 – 20 m/min
- Minimum workpiece length 250 mm
- Main motor power 5.5 kW, 50 Hz
- Noise level (according to EN27960 standard) 86 – 90 dB(A)
STANDARD FEATURES
- Table lifting via 4 trapezoidal screws
- Automatic raising and lowering of the table with micrometric adjustment
- Working height reading with 0.1 mm accuracy
- Suction hood Ø 150 mm
- Safety switch (micro switch) on the door
