Description
- Panel dimensions:
- Panel Length (X): 200 – 3200 mm,
- Panel Width (Y): 35 – 1250 mm,
- Panel Thickness (Z): 8 – 60 mm,
- Max. working panel weight: 50 Kg,
- HP Kit for the expedited management of the panel-handling grippers. Allows to obtain a movement speed of up to 110 m/min with fast acceleration ramps,
Double Axes Equipment For Self-Selecting Drilling Unit, Composed of:
- BH21 Lower Self-selecting drilling unit with 13 vertical + 4 horizontal spindles,
- BH23 Upper Self-selecting drilling unit with 14 vertical + 4 horizontal spindles + 1 grooving saw d. 120 mm,
- 11 kW Electrospindle with HSK-F adaptor,
- Tool changer 8 positions,
- Laser Y-reading device,
- Working surface kit for delicate surfaces.
