Description
- Max cutting thickness: 180mm (for blades diameter 350mm)
- Max cutting width: 350 mm
- Max width of board passage: 800 mm
- Min length of workpieces: 700 mm
- Diameter of fixed saw blades: min/max 250/350 mm, hole diameter 70, 2 pcs. keyway 20 x 6
- 7 independent pressure rollers
- Anti kickback device
- Feed speed adjustable by inverter: 0-30 m/min
- Feed belt motor: 2 x 2.25 kW
- Feed belts width (input and output): 500 mm
- Dust extraction ports: 2 x Ø 250 mm, speed 30 m/s, 5300 m³/h
- Main motors versions (per 1 spindle): 22 kW; 30 kW; 37 kW; 44 kW; 55 kW
- Manual oil pump
- Chain belt automatic lubrication
- Pressure group motor: 1.5 kW
- Weight: 6500 kg
Machine dimensions:
- Length: 280 cm
- Width: 225 cm
- Height: 175 cm
