Description
- Max cutting thickness: 270mm (for blades diameter 450mm)
- Max cutting width: 400 mm
- Max width of board passage: 800 mm
- Min length of workpieces: 900 mm
- Diameter of fixed saw blades: min/max 350/450 mm, hole diameter 90, 2 pcs. keyway 20 x 6
- 8 independent pressure rollers
- Anti kickback device
- Feed speed adjustable by inverter: 0-30 m/min
- Feed belt motor: 2 x 3 kW
- Feed belt width input: 600 mm
- Feed belt width output: 700 mm
- Dust extraction ports: Ø 300 mm, speed 30 m/s, 7600 m³/h; and Ø 250 mm, speed 30 m/s, 5300 m³/h
- Main motors versions (per 1 spindle): 55 kW; 75 kW; 92 kW; 110 kW; 135 kW
- Manual oil pump
- Chain belt automatic lubrication
- Pressure group motor: 1.5 kW
- Weight: 10.000 kg
Machine dimensions:
- Length: 305 cm
- Width: 233 cm
- Height: 195 cm
