Description
Dimensions:
- Length 4,690 mm
- Width 1,190 mm
- Height 6,900 mm
Centrifugal Fan Model FQ 631:
- Three-phase electric motor, 4-pole
- Power: 30 kW
- Power supply: 380/660 V
- Motor support
Technical parameters:
- Efficiency: 19,000 m³/h
- Density: 1.226 kg/m³
- Static pressure: 301 kgf/m²
- Dynamic pressure: 49 kgf/m²
- Total pressure: 350 kgf/m² at 15°C
- Speed: 2,850 rpm
- Power consumption: 24.6 kW at 15°C
- Installed power: 30 kW
- Efficiency: 87%
- Maximum speed: 3,000 rpm
- Weight: 390 kg
- Noise level at a distance of 1.5 m: 84 dB
- Device complies with CE standards
