Description
- Max cutting thickness: 120mm (for blade diameter 400mm)
- Max cutting width: 450 mm
- Max width of board passage: 800 mm
- Min length of workpieces: 600 mm
- Diameter of fixed saw blades: min/max 300/400 mm, hole diameter 70, 2 pcs. Keyway 20 x 6
- 5 independent pressure rollers
- Anti kickback device
- Pressing roller unit with motor: 1.1 kW
- Feed speed adjustable by inverter: 0-50 m/min
- Feed belt motor: 3 kW
- Feed belt width: 450 mm
- Upper dust extraction port: Ø 300 mm, speed 30 m/s, 7600 m³/h
- Main motor versions: 44 kW
- Automatic oil pump
- Chain belt automatic lubrication
- Weight: 5400 kg
Machine dimensions:
- Length: 205 cm
- Width: 215 cm
- Height: 201 cm
