Description
Loading and unloading from the front – this type of feeding system and the simplified drilling process make it possible to complete the drilling in a single process. Independent board feeding effectively protects the workpieces from damage. Counting workpieces, positioning, storing, drilling are all made easy thanks to an innovative system for easy operation.
- Dimensions:
- Length (X) 200 1500 mm,
- Width (Y) 30 200 mm,
- Thickness (Z) 10 25 mm,
- Number of vertical spindles: 7*2 rows,
- Number of horizontal spindles: 7*2 rows,
- Drill motor power: 1.5 kW * 4,
- Distance between drills: 32 mm,
- Maximum vertical drilling depth: 25 mm,
- Maximum horizontal drilling depth: 45 mm,
- Total power: 7 kW,
- Approximate machine weight: 1 800 kg,
- External dimensions of the machine: 3 150 * 1 520 * 1 820 mm.
