CARTON CUTTING AND CREASING MACHINE NANXING BZX-3500

Description

• Equipped with up to 12 cardboard stacks with AI optimization for maximum material usage.
• Cutting capacity: 6–13 boxes per minute (depending on mode and carton type).
• 13 servo drive sets for precise motion control.
• 1 horizontal and 8 vertical cutting knives (Japanese-made, with high durability).
• Roller system with anti-jamming design, guiding plates, and telescopic flow controllers to prevent carton clogging.
• Industrial-grade motion controller with dedicated CP cutting software.
• Multiple communication protocols (ModbusTCP/IP, CSV, MySQL, MES integration).
• Custom box design and size adjustment.
• Multi-box cutting modes, mirror production, one-click repeat or quick cutting, self-cleaning mode.

• Production capabilities:
  • Corrugated board thickness: 2.5–6.5 mm.
  • Corrugated board width: 350–2500 mm.
  • Max stacking height: 1500 mm (including pallet).
  • Longitudinal cutting tolerance: ≤0.5%.
  • Cross cutting tolerance: ±2 mm.

• Technical specifications:
  • Machine dimensions: 15600 × 3500 × 3000 mm.
  • Power: 15 kW (approx. 4 kW actual consumption).
  • Rated current: 6.5 A.
  • Voltage: 380 V / 50 Hz / 3-phase.
  • Air supply: 0.6 MPa, 20–100 L/min.
  • Machine weight: approx. 3000 kg.
