Description
- Milling unit with pneumatic spindle, 0.62 kW / 11,000 rpm
- Copying device with teflon copying ring
- Gear motor for the milling unit with 0.55 kW motor
- Rotational speed adjustable via inverter
- Work cycle controlled by PLC
- 1 adjustable worktable with locking actuator included
- Possibility to copy directly on the element or using a template
- Working cross-section: max 120 x 120 mm / min 20 x 20 mm
- Minimum length: 150 mm
- Maximum chamfer: 5 x 45° mm or radius r = 5 mm
- Dimensions: 800 x 1200 x 1700 mm (H) / Weight: 550 kg
- Construction compliant with CE standards
- Voltage: 400 V / 50 Hz
